Optio™ B

MULTI-GAS MONITOR FOR LI-ION BATTERY SAFETY

The Optio B is a stand‑alone multi‑gas detector engineered specifically to monitor Li‑ion battery systems for early signs of thermal runaway. The Optio B uses three dedicated sensors that continuously monitor for carbon dioxide (CO₂), hydrogen (H₂), and volatile organic compounds (VOCs) to before visible smoke or flame appears.

Onboard relays, 4-20mA outputs, and Modbus communication makes it easy to integrate the Optio B with a building automation system (BAS) or battery management system (BMS) for centralized monitoring and alarming.

PRODUCT FEATURES
  • Long Sensor Life – Designed for extended operational longevity, reducing replacement frequency and lowering maintenance costs.
  • Self-Diagnostic Function – Continuously monitors internal health to ensure reliable system performance and early fault detection.

  • Automatic Reset – Recovers seamlessly after power loss, minimizing manual intervention.

  • Onboard Relay Contacts – Provides built-in relays for direct control of external devices, alarms, or ventilation functions.
  • Optional Dual 4–20 mA Outputs – Offers two analog outputs for integration with building management or automation systems.

  • Onboard 80 dB Alarm – Delivers a loud, clear audible warning to alert personnel to hazardous conditions.

  • Bright LCD Display – High-visibility screen ensures clear viewing of gas readings and status information in various lighting conditions.

  • Flexible Sensor Configuration – Supports a combination of internal and remote/external sensors.

Sensor Configurations

  • Sensors (Capable of up to 18 total)
    • All sensors remotely installed.
  • 3 NDIR (Non-Dispersive Infrared)
    • CH4, CO2, & H2
  • 3 Plug and Play Electrochemical Sensors
    • Preconfigured & Pre-calibrated
    • O2, CO, & VOC


Mechanical

  • Dimensions: 4 in × 4 in × 2 in
    (102 mm × 102 mm × 51 mm)
  • Weight: 3 lb (1.4 kg)


Environmental

  • Operating Temperature: -4°F to +113°F
    (-20°C to +45°C)
  • Operating Humidity: 15–90% RH non-condensing


Electrical

  • 6–30 VDC
  • 24–120 VAC 50/60 Hz


Alarms

  • Supports 4 custom alarm levels with hysteresis and hold-to-alarm timing, fail-high/low alarms, and relay output logic (AND/OR) based on single or multiple sensor inputs.


Communication Interfaces

  • RS-485
  • Modbus RTU


I/O Capabilities

  • 6 Relay Outputs: 250 VAC, 220 VDC, 2 A
  • 6 Multi-Function Ports: DI/DO/AI (0–5 V, 0–3.6 V)
  • Output Signal: 2 × 4–20 mA


Power Consumption

  • Maximum 50 mA, 24 VDC

Capable of up to 18 total (remotely installed)

  • 3 NDIR (Non-Dispersive Infrared)
    • CH4, CO2, & H2
  • 3 Plug and Play Electrochemical Sensors
    • O2, CO, & VOC
  • Datacenters
  • Battery Rooms
  • BESS Containers
  • Boiler & Mechanical Rooms
  • UL Standard: UL 61010-1, 3rd Edition + AM1:2018 (pending)

  • Canadian Standard: CAN/CSA-22.2 No. 61010-1-12, 3rd Edition + AM1:2018 (pending)
