With no specialist tools or knowledge needed for installation and operation, the Fireray One is a standalone beam smoke detector that prioritizes ease of installation. No specialist tools required to install or operate, with minimal prior knowledge and training needed.
Using the Fireray One, it couldn’t be easier to bring the benefits of beam smoke detection to your application. With Auto-Alignment™, just steer the laser onto the Reflector, then at the flick of a switch, it aligns itself — 8 times faster than previous detectors.
Detection Range: 16 to 164 ft (5 to 50 m); 16 to 394 ft (5 to 120 m) with Reflective Long Range Kit
Alignment Method: Laser assisted, Auto-Alignment™; Manual alignment – optional setting
Auto-Alignment™ Protocol: Background check, Box search, Adjust and Center
Building Movement Tracking™: Compensates for natural shifts in alignment from building movement
Contamination Compensation: Compensates for gradual build-up of contamination on the optical surfaces
Light Cancellation Technology™: Compensates for high levels of sunlight and artificial lighting
Optical Wavelength – Smoke Detection: 850 nm near infrared (invisible)
Integrated Laser – Laser Alignment: 650 nm visible, Class 3R <5 mW
Dynamic Beam Phasing: Allows beam detectors to be mounted facing each other with the reflectors in the middle; eliminates false alarms caused by crosstalk between beams
Signal Output: Individual Alarm and Fault relays (VFCO) 0.5 A @ 30 VDC
Operating Voltage: 14 to 36 VDC
Operating Current (Constant): All operational modes – 5 mA; Fast alignment mode – 33 mA
Field Wiring – Cable Gauge and Type: 2 core, dedicated, 24 to 14 AWG (0.5 to 1.6 mm); compatible with fireproof and non-fireproof cable meeting local installation standards
Field Wiring – Cable Entry: 3 knock-out locations capable of accepting M20, ½” or ¾” glands; 4 drill-out locations capable of accepting glands up to 0.82″ (21 mm) diameter
Operating Temperature: -4 to 131 °F (-20 to +55 °C)
Storage Temperature: -40 to 185 °F (-40 to +85 °C)
Relative Humidity: 0 to 93% (non-condensing or icing)
Fault Level / Rapid Obscuration (∆ ≤ 2 sec): ≥85%
Maximum Angular Alignment of Reflective Detector: ±4.5° (±70° with adjustment bracket accessory)
Maximum Angular Misalignment of Reflective Detector: ±0.5°
Maximum Angular Misalignment of Reflector: ±5°
IP Rating: IP55
Housing Flammability Rating: UL94 V0 polycarbonate
UL – S3417
ULC – S3417
CSFM – 7260-1508-105
Light Cancellation Technology™ Patent No. GB2513366
Dynamic Beam Phasing Patent pending
Auto-Alignment™ Patent pending
